BONFIGLIOLI Active Cube User Manual

03/12 EM-ABS-01 for ACU 83
The capacity planning are planned and documented with the help of the table. The
work sheet is available as a Microsoft Excel document "Load_Systembus.xls" on the
VECTRON product CD or by request.
Load system bus
Baud rate [kBaud]:
50, 100, 125, 250, 500, 1000
1000
Frequency
inverter
TxPDO
Number
Ta
[ms]
Workload
[%]
1 1 0 0
2 0 0
3 0 0
2 1 0 0
2 0 0
3 0 0
3 1 0 0
2 0 0
3 0 0
4 1 0 0
2 0 0
3 0 0
5 1 0 0
2 0 0
3 0 0
6 1 0 0
2 0 0
3 0 0
7 1 0 0
2 0 0
3 0 0
8 1 1 14
2 1 14
3 1 14
9 1 1 14
2 1 14
3 0 0
10 1 0 0
2 0 0
3 0 0
Total workload [%] 70
In the table, the set baud rate is entered from the parameter
Baud Rate 903in
kBaud. For each frequency inverter, the set time for the transmission interval (e. g.
TxPDO1 Time 931) in ms is entered for the TxPDO being used at the time. In the
column Load the bus load caused by the individual TxPDO appears, under Total
Load the entire bus load.
For the bus load (Total load) the following limits have been defined:
≤ 80 %
Î OKAY
80 ... 90
%
Î CRITICAL
> 90 %
Î NOT POSSIBLE
