92 EM-ABS-01 for ACU 03/12
8.2 Digital outputs EM-S1OUTD and EM-S2OUTD
8.2.1 General
Parameterization of the digital outputs permits a linkin
to a variety of functions. The
selection of the functions depends on the parameterized configuration.
8.2.2 Operation modes
The operation mode of digital output EM-S1OUTD (Terminal X410A.3) is done via pa-
rameter
Operation mode EM-S1OUTD 533. By default, this parameter is set to “41 -
Open brake”.
The operation mode of digital output EM-S1OUTD (Terminal X410A.4) is done via pa-
rameter
Operation mode EM-S2OUTD 534. By default, this parameter is set to “0 -
Off”.
he operation modes to be selected correspond to the table shown in the operatin
instructions of the frequency inverter in the chapter "Digital outputs“.
8.2.3 Repetition frequency output via EM-S1OUTD and EM-S2OUTD
Digital outputs EM-S1OUTD and EM-S2OUTD can be used as repetition frequency out-
puts. The output value of the repetition frequency output corresponds to the mechani-
cal frequency of the connected encoder.
Digital outputs EM-S1OUTD and EM-S2OUTD can be set up as a repetition frequency
output via parameter
Repetition frequency EM-S1/2OUTD 509.
Repetition frequency EM-S1/2OUTD
509
Function
0 - Off Reference frequency output is turned off.
Factory setting.
1 - On The repetition frequency output via digital
outputs EM-S1OUTD and EM-S2OUTD is
turned on. The number of division marks of
the repetition frequency output corresponds
to the number of encoder division marks (set
via
Division marks 1183, see chapter 8.4.1).
