03/12 EM-ABS-01 for ACU 13
he extension module is assembled simply by plu
in
on without tools bein
needed
thanks to the modular set-up of the frequency inverters of the ACU series of devices.
Caution! Carry out the assembly of the extension module before the frequency
inverter is put into operation, and only in a voltage-free state.
The plug-type terminals of the extension module enable economical overall fittin
with
a safe function.
Note:
Chapter 10.2 contains a compatibility list of the EM-ABS-01 modules in
combination
with the ACU inverter firmware versions.
3.1 Restrictions for operation of standard functions
Note: If an EM-ABS-01 module is used with an ACU device, the following func-
tions of the basic device can no longer be used:
• Repetition frequency mode via MFO1 of base device.
Instead, repetition frequency mode can be realized via digital out-
puts of the EM-ABS-01 module.
• Repetition frequency mode (also PWM frequency input) via di
ital
inputs of basic device
Instead, the speed sensor 1 input of the basic device can be used.
