26 EM-ABS-01 for ACU 03/12
5.3.3 Power supply
Encoder power supply can be effected in different ways. Dependin
g
on the consumers
connected, there are different encoder power supply possibilities or requirements.
Generally, there are three different application types:
Low power demand (< 0.5 W) and power supply 12 V:
Î Internal power supply.
Medium power demand (0.5... 2 W) and power supply 12 V:
Î Power supply to be looped via X410.
High power demand (> 2 W) or power supply > 12 V:
Î Connect encoder directly to external power supply.
Encoders with high power demand (> 2 W) or voltage higher than DC 12 V must be
connected to an external power supply directly.
External power supply can be connected via terminals X410A for encoder supply. In
this case, a DC 24 V supply can be controlled down, by the EM-ABS-01 module, to the
frequently needed voltage levels DC 5…12 V.
5.3.3.1 Internal power supply
Encoders with a low power consumption (< 0.5 W) can be supplied, in most cases, by
the internal power supply unit.
Set parameter Power supply 1186 to either “1 - internal” or “5- internal, sense”. See
chapter 8.4.3 “Power supply”.
The voltage level can be
set up via parameter
Supply voltage 1187. See chapter
8.4.4 “Supply voltage”.
The encoder can be powered as follows:
via control terminals X410A.5 (DC 5 … 12 V) and X410A.7 (GND) or
via contacts X412.6 (VEnc) and X412.15 (GND) of the female HD-Sub-D connec-
tor.
See chapter 5.3.2 "Control terminals".
Caution! If power supply is done via the internal power supply of the encoders, a
total power of 2 W is available for all consumers connected to digital, ana-
log and encoder interfaces. This includes all interfaces of the ACU basic
device and the EM-ABS-01 module together.
