8.4 Encoder input EM-ABS-01
The encoder input is used for evaluating the position information from the encoder.
Dependin
g
on the encoder system used, certain parameters need to be set up. The
following table describes the use of the individual parameters for the encoder systems.
Parameters Encoder system
No. Description SinCos Hiperface EnDat 2.1 SSI
513 EC2 Gear Factor Numerator X X X X
514 EC2 Gear Factor Denominator X X X X
1183 Division marks X X X (X)
1184 Encoder signals/log X X X X
1186 Power supply X X X X
1187 Supply voltage X X X X
1188 Offset 1)
1268 SSI: Sampling interval --- --- --- X
1269 SSI: Error-/Extra-Bits (Low) --- --- --- X
1270 SSI: Error-/Extra-Bits (High) --- --- --- X
1271 Bits/Turn --- X --- X
1272 Bits Multiturn --- X --- X
X: Parameter must be configured according to the encoder data sheet.
--- Parameter has no function for this encoder type.
(X): In the case of SSI encoders the evaluation of the division marks depends on the
setting of
Tracks/Protocol 1184.
1): Setting the offset is required in the case of synchronous motors.
In addition, the following actual value parameters are available:
Parameters Encoder system
No. Description SinCos Hiperface EnDat 2.1 SSI
1267 Abs. encoder raw data --- X X X
1274 Warning Dig. Encoder --- --- X ---
Note: If positionin
g
(confi
g
urations x40) is used, please note to the instructions
in chapter
8.4.11.1.
Note:
Gear factors EC2 Gear Factor Numerator 513 and
E
C2 Gear Facto
r
D
enominato
r
514 are not available in configurations 5xx.
8.4.1 Division marks
In parameter Division marks 1183, you can set the type-specific number of division
marks of the encoder. The number of division marks is typically described in ampli-
tudes/revolution in the case of encoders with SinCos tracks. Enter the division marks or
amplitudes/revolution in parameter
Division marks 1183.
Parameters Settings
No. Description Min. Max. Factory set-
ting
1183 Division marks 0 8192 1024
Note:
In the case of SSI absolute value encoders, evaluation of Division marks
1183 is active only if Tracks/Protocol 1184 is described in an operation
mode for evaluation of TTL [RS-422] or SinCos tracks (settin
g
s 51xx,
59xx, 61xx and 69xx).
