56 EM-ABS-01 for ACU 03/12
OS_SyncSource 1452
Operation mode Function
0 -
uto The synchronization source is selected automatically by the
frequency inverter.
1 - CANopen The operating system is synchronized via CANopen. Factory
setting.
2 - System bus The operating system is synchronized via system bus.
3 - Off The operating system is not synchronized.
Operation mode Auto: Selection is made via a decision table:
CANopen active System bus active Synchronization
es
es
Î Synchronization via CANopen
es No
No
es Î Synchronization via system bus
No No Î No synchronization activated.
Status “Synchronization via CANopen active” is identified via parameter setting 387
CAN Node Number >1 and a running synchronous PDO.
Status “Synchronization via system bus active” is identified via parameter setting 900
System bus node ID >1. In addition, parameter 1180 Synchronization must be set to
SYNC or RxPDO.
The source of the operating system (OS) synchronization is set via 1180 Operation
mode
. This defines the Sync event (RxPDO or SYNC telegram), which will be used fo
synchronization of PDOs:
930 TxPDO1 Function
932 TxPDO2 Function
934 TxPDO3 Function
936
RxPDO1 Function
937 RxPDO2 Function
938 RxPDO3 Function
Synchronization Operation mode 1180
Operation mode Function
0 - Off Synchronization via system bus is deactivated. Factory set-
ting.
1 - RxPDO1 Synchronization via system bus is activated via RxPDO1.
2 - RxPDO2 Synchronization via system bus is activated via RxPDO2.
3 - RxPDO3 Synchronization via system bus is activated via RxPDO3.
10 - SYNC Synchronization via system bus is activated via SYNC.
