BONFIGLIOLI Active Cube User Manual

64 EM-ABS-01 for ACU 03/12
Display of node ID system bus in the BONFIGLIOLI VECTRON bus protocol:
System bus Node-ID
System bus
address
(ASCII)
charac-
ter
HEX value System bus
address
(ASCII) cha-
racter
HEX value
1 A 41 31 _ 5F
2 W 42 32 ` 60
3 C 43 33 a 61
4 D 44 34 b 62
5 E 45 35 c 63
6 F 46 36 d 64
7 G 47 37 e 65
8 H 48 38 f 66
9 I 49 39 g 67
10 J 4A 40 h 68
11 K 4B 41 i 69
12 L 4C 42 j 6A
13 M 4D 43 k 6B
14 N 4E 44 l 6C
15 O 4F 45 m 6D
16 P 50 46 n 6E
17 Q 51 47 o 6F
18 R 52 48 p 70
19 S 53 49 q 71
20 D 54 50 r 72
21 U 55 51 s 73
22 V 56 52 t 74
23 W 57 53 u 75
24 X 58 54 v 76
25 Y 59 55 w 77
26 Z 5A 56 x 78
27 [ 5B 57 y 79
28 \ 5C 58 z 7A
29 ] 5D 59 { 7B
30 ^ 5E 60 | 7C
61 } 7D
62 ~ 7E
63

7F
