BONFIGLIOLI Active Cube User Manual

96 EM-ABS-01 for ACU 03/12
Tracks/Protocol 1184
Function
SSI
Gray code
5001
SSI, Gray code,
141 kBit/s
Evaluation of data and clock tracks with the SSI protocol
(without TTL or SinCos track). The data track is transmitted at
140.625 kBaud in Gray code.
This function is currently be-
ing prepared
!
5002
SSI, Gray code,
281 kBit/s
Like 5001. The data track is transmitted at 281.25 kBaud in
Gray code.
5005
SSI, Gray code,
563 kBit/s
Like 5001. The data track is transmitted at 562.5 kBaud in
Gray code.
5011
SSI, Gray code,
1125 kBit/s
Like 5001. The data track is transmitted at 1125 kBaud in Gray
code.
5101
SSI+SINCOS, Gray
code, 141 kBit/s
Evaluation of Tracks/Protocol A/B as SINCOS track and the
data and clock tracks with the SSI protocol. The data track is
transmitted at 140.625 kBaud in Gray code.
5102
SSI+SINCOS, Gray
code, 281 kBit/s
Like 5101. The data track is transmitted at 281.25 kBaud in
Gray code.
5105
SSI+SINCOS, Gray
code, 563 kBit/s
Like 5101. The data track is transmitted at 562.5 kBaud in
Gray code.
5111
SSI+SINCOS, Gray
code, 1125 kBit/s
Like 5101. The data track is transmitted at 1125 kBaud in Gray
code.
5901
SSI+TTL, Gray
code, 141 kBit/s
Evaluation of Tracks/Protocol A/B as TTL [RS-422] track and
the data and clock tracks with the SSI protocol. The data track
is transmitted at 140.625 kBaud in Gray code.
5902
SSI+TTL, Gray
code, 281 kBit/s
Like 5901. The data track is transmitted at 281.25 kBaud in
Gray code.
5905
SSI+TTL, Gray
code, 563 kBit/s
Like 5901. The data track is transmitted at 562.5 kBaud in
Gray code.
5911
SSI+TTL, Gray
code, 1125 kBit/s
Like 5901. The data track is transmitted at 1125 kBaud in Gray
code.
SSI
Binary code
6001
SSI, binary code,
141 kBit/s
Evaluation of data and clock tracks with the SSI protocol
(without TTL or SinCos track). The data track is transmitted at
140.625 kBaud in binary code.
This function is currently
being prepared
!
6002
SSI, binary code,
281 kBit/s
Like 6001. The data track is transmitted at 281.25 kBaud in
binary code.
6005
SSI, binary code,
563 kBit/s
Like 6001. The data track is transmitted at 562.25 kBaud in
binary code.
6011
SSI, binary code,
1125 kBit/s
Like 6001. The data track is transmitted at 1125 kBaud in bi-
nary code.
6101
SSI+SINCOS,
binary code, 141
kBit/s
Evaluation of Tracks/Protocol A/B as SINCOS track and the
data and clock tracks with the SSI protocol. The data track is
transmitted at 140.625 kBaud in binary code.
6102
SSI+SINCOS,
binary code, 281
kBit/s
Like 6101. The data track is transmitted at 281.25 kBaud in
binary code.
6105
SSI+SINCOS,
binary code, 563
kBit/s
Like 6101. The data track is transmitted at 562.25 kBaud in
binary code.
6111
SSI+SINCOS,
binary code, 1125
kBit/s
Like 6101. The data track is transmitted at 1125 kBaud in bi-
nary code.
6901
SSI+TTL, binary
code, 141 kBit/s
Evaluation of Tracks/Protocol A/B as TTL [RS-422] track and
the data and clock tracks with the SSI protocol. The data track
is transmitted at 140.625 kBaud in binary code.
6902
SSI+TTL, binary
code, 281 kBit/s
Like 6901. The data track is transmitted at 281.25 kBaud in
binary code.
