4.8 Overview of the water chillerG1
electrical cabinet
2
3
4
5
6
4588963-91_Pal
1
Fig. 15: Front view
1 Controller A1
2 Cable gland (fan M2-EV1)
3 Cable gland (water pump M3)
4 PE terminal block
5 Cable gland (pressure sensors PV1 and HP1, temperature sensor
B2 a level sensor)
6 Cable gland (compressor M1-MC1)
Fig. 16: Front view of controller A1
Fig. 17: Rear view of controller A1
14
15
1
2
3
4
5
6
7
8 9
10
11
17
13
12
16
4588963-90_Pal
Fig. 18: View of the inside
1 Contactor KM1
2 Contactor KM5
3 Contactor KM7
4 Motor circuit breaker F1
5 Terminal block X0
6 Terminal block X1
7 Fuse FU1
8 Relay KA1
9 Relay KA2
10 Circuit breaker FU1
11 Circuit breaker FU2
12 Wireway
13 Transformer TC1
14 Terminal J3
15 Terminal J4
16 Wireway
17 PE terminal block
R1 S1 T1
4
11 20
0
30 61
021033
13 22
COM
B2 60
62
022
10
034
1
2
458863-92_pal
Fig. 19: Terminal blocks X0 and X1
1 Terminal block X0
2 Terminal block X1
