Bosch FPA-5000 System Information Guide

10 en | Product Description Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
Module Description Function
ANI 0016 A Annunciator Module Indicating system statuses; with 16 red and 16
yellow freely programmable LEDs
BCM-0000-B Battery Controller
Module
Monitoring the power supply to the panel and the
battery charge level
CZM 0004 A 4 Zone Conventional
Module
Connecting existing conventional peripherals using
four monitored conventional lines
ENO 0000 B Fire Service
Interface Module
Connecting fire service equipment complying with
DIN 14675
FPE-5000-UGM Interface Module Connection to UGM systems
IOP 0008 A Input/Output OC
Module
Individual displays or flexible connection of various
electrical devices, with 8 independent digital inputs
and 8 open collector outputs
IOS 0020 A 20mA
Communication
Module
With S20, RS232 and S1 interfaces
IOS 0232 A RS232
Communication
Module
Connection of two devices using two independent
serial interfaces, e.g. a Plena Voice Alarm System,
laptop or printer.
LSN 0300 A LSN improved
Module 300mA
Connection of an LSN loop with up to 254LSN
improved elements or 127LSN classic elements at a
maximum line current of 300mA
LSN 1500 A LSN improved
Module 1500mA
Connection of an LSN loop with up to 254LSN
improved elements at a maximum line current of
1500mA or 127LSN classic elements at a maximum
line current of 300mA
NZM 0002 A Notification
Appliance Zone
Module
Allows connection of two conventional, monitored
notification appliance circuit lines
RMH 0002 A Relay Module Monitored connection of external elements with
feedback, with two changeover contact relays
suitable for switching mains voltage
RML 0008 A Relay Module For low voltage switching, with eight changeover
contact relays
Further information can be found in Functional Modules, page 99.
The technical data can be found in Housing and Accessories, page 146.
Notice!
Planning Software by Bosch can be used to plan fire alarm systems that conform to the
relevant limits (e.g. in terms of cable length and power supply).

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
