14 en | Product Description Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
The modular system makes it easy to extend the system.
Housing Designs and Combinations
Two frame installation housings are available as a base unit:
– CPH0006A (for 6 modules) or
– MPH0010A (for 10 modules)
These housings can accommodate an MPCPanel Controller with an operating and display unit.
The CPH0006A and MPH0010A basic housings can be extended to meet individual
requirements using:
– EPH0012A extension housing for an additional 12 modules, frame installation
– PSF0002A or PMF0004power supply housing for two or four 12V/45Ah batteries
respectively and an additional power supply unit.
– USF0000A Universal Housing Small, Frame Installation.
A power supply bracket for a UPS power supply is fitted ex-works in housing units
CPH0006A, PSF0002A and PMF0004A.
Mounting Frames
All mounting frames have integrated terminal blocks for the mains supply, integrated junction
boards, as well as permanently installed cable ducts to facilitate clear and tidy cable routing.
The mounting frames are available in three sizes:
– FBH0000A Mounting Frame Large
– FMH0000A Mounting Frame Medium
– FSH0000A Mounting Frame Small
The large mounting frame is also available in a design with a distributor rail complying with
EN60715:
– FHS0000A Mounting frame large with distributor rail
The housings for frame installation require the following mounting frames for surface-mounted
version:
Housing type Mounting frames
CPH 0006 A FBH 0000 A / FHS 0000 A
MPH 0010 A FBH 0000 A / FHS 0000 A
EPH 0012 A FBH 0000 A / FHS 0000 A
PSF 0002 A FSH 0000 A
PMF 0004 A FMH 0000 A
USF 0000 A FSH 0000 A
Notes:
– All mounting frames have an opening for routing cables that is sealed with an insert. Pre-
punched cable entries can be created from this insert.
– The FBH0000A and FHS0000A mounting frames are equipped with an earth bar ex
works.
– For the FMH0000A, the FPO‑5000‑EB Earth Bar can be ordered as an extension if
required.
– For continuous installation in combination, all mounting frames have T-shaped guide rails
on the base and T-shaped grooves on the top.
