M410 User Manual 49
Editing Labels on the Printer
Serialization (Sequential Data)
Increment:1
Produces:1, 2, 3, 4, 5, 6, 7, 8, 9, 10
Simple Alphanumeric Example
You can combine letters and numbers in a single serialization. When the right-most character in the
Start Value reaches its maximum value (9, Z), the character immediately to the left is incremented, and
the right character cycles back to its minimum value (0, A)
Example:
Start Value:A1
End Value:D4
Increment:1
Produces:A1…A9, B0…B9, C0…C9, D0...D4
Advanced, Independent Example
In a multi-sequence serialization, where the second set of values is NOT dependent on the first set
(that is, the Linked box is NOT selected), the two sequences increment sequentially, independent of
each other.
Example: Two sequences that increment independently:
Advanced, Dependent Example
In a multi-sequence “linked” serialization (the Linked box is selected), the second set of values is
dependent on the first set. The second sequence holds its initial value until the first sequence
completes, after which it moves to the next value.
Example: Two sequences that increment dependently.
Add Serialization
To add serialization to labels:
1. Position the cursor on the label where you want the serialization to display.
2. Press .
Sequence #1 Sequence #2
Start Value:
1Start Value: A
End Value:
10 End Value: C
Increment:
1 Increment: 1
Produces: 1A, 2B, 3C, 4A, 5B, 6C, 7A, 8B, 9C, 10A, 1B,
2C, 3A, 4B, 5C …
Sequence #1 Sequence #2
Start Value:
1 Start Value: A
End Value:
10 End Value: C
Increment:
1 Increment: 1
Produces: 1A…10A, 1B…10B, 1C…10C
