M410 User Manual 52
5 Label Types
Label types provide templates that guide and control the layout for specific applications. Some label
types require specific label supplies. To select a label type, press and see the following
sections for more details on each.
General ..................................................................................................................... 52
Wire Marker .............................................................................................................. 52
Flags ......................................................................................................................... 54
Terminal Block, Patch Panel, 66-Block.................................................................. 55
110-Block, Bix Block ............................................................................................... 57
DesiStrip (Designation Strip).................................................................................. 60
Breaker Box.............................................................................................................. 60
Depending on the label type chosen, a sub-menu or dialog box displays to collect information for
automatically formatting the specific label type.
The name of the specific label type being used is displayed in the upper left corner of the screen,
below the font size. See “Using the Screen” on page 21.
General
The General label type contains standard functions and formats used for most generic labels, but does
not provide templates as do other label types.
If you have been working with another label type and want to return to the General label type, perform
the following steps.
To select the General label type:
1. Press .
2. Use the navigation keys to highlight General.
3. Press
.
See Chapter 4: Editing Labels on the Printer beginning on page 33 for instructions on using the editing
tools for the General category of labels.
Wire Marker
The Wire Marker label type is designed to repeat entered data down the length of the label. The data
repeats as many times as possible, considering the font size and the wire size selected.
