M610 Label Printer User Manual 4
Setup
Printer Components
Printer Components
1 Cover 9 Printhead lock lever
2 Cover release latch 10 Bulk or external label feed path
3 Power button 11 Magnet attachment screw holes
4 AC adapter port 12 Tripod attachment screw hole
5 USB port (computer connection) 13 Battery door latch
6 USB host port (USB drive) 14 Battery door (battery well)
7 Cutter lever 15 Serial number
8 Ribbon
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
