Procedural Instructions on the TSC
8
SpaceStation, 2.0 gb 8- 5
2.0
5. Reconnect the SpaceStation to the mains. The status display
colour on the operator and status display field of the Space-
Cover comfort changes from yellow to green.
Interface Check of the SpaceStation with SpaceCom
1. Insert a pump in the SpaceStation.
2. Connect a PC to the SpaceStation via the interface cable RJ-
45 cross-over and start the Space-Online Program (see
„SpaceOnline“ ➨ S. 1 - 17).
3. Check in the Service Part whether the correct pump type and
its On-/Off-status are displayed.
Note
If the IP-address of the SpaceStation is unknown, all parameters
can be reset to the factory settings from software version
695E010001 on via a USB-stick with the „factorydefault” directo-
ry saved here. When the word „factorydefault“ is read automati-
cally resetting of the parameters in the SpaceStation is started.
The IP-address of the SpaceStation is set to 192.168.100.41.
4. Connect a PC with the SpaceStation via the interface cable
RS232 SPCO (crossed) and start the BCCshow Program (see
„BCCshow“ ➨ S. 1 - 19).
5. Check whether the correct pump and its status are displayed
on the PC.
Battery Check of the SpaceStation with SpaceCom
1. Insert one battery module in the SpaceStation and one in the
SpaceCover comfort. After start-up the battery charge condi-
tion is displayed in the bottom charge condition display of
the operator and status display field of the SpaceCover com-
fort.
2. Remove the battery module out of the SpaceCover comfort.
3. Disconnect the SpaceStation from mains when the status in-
dicator (green) on the SpaceCom (SpaceCom is operative)
lights up.
4. The status indicator (green) on the SpaceCom remains on for
at least 3 seconds. The alarm indicator (red) must not light up
or flash.
5. Remove the optional battery modules which are not part of
the unit out of the device.
