System Overview
1
1- 6 SpaceStation, 2.0 gb
Function
SpaceStation without SpaceCom
The SpaceStation supplies the inserted pumps as well as a Space-
Control connected to the pumps with the required voltage. The
voltage is generated by the integrated power supply, which is con-
nected to the supply mains via the connector “F1A” and a mains
cable or an upstream SpaceStation. The mains voltage is trans-
mitted via the internal cabling to connector “F1B“ for connection
of a further SpaceStation.
The pumps are connected with connectors “F2A” to “F2D” to the
SpaceStation. These connectors provide the voltage supply, dis-
tribute the addresses in the Space system via a serial interface,
transfer data via a bus system (CAN bus) and transmit a staff call,
which may be pending.
Another SpaceStation inserted on top or a SpaceCover is integrat-
ed in the Space system via connector “F5“.
Connector “F4“ is used for connecting another SpaceStation or
further SpaceStation columns. An upstream SpaceStation or an
upstream SpaceStation column as well as accessories that may be
connected, such as a PCA button or a service connector, are con-
nected to connector “F3“.
2.0
