Disassembly / Assembly SpaceCover
5
5- 12 SpaceStation, 1.0 gb
1.0
Housing Upper Part
Note
Pay attention to the correct position of the loudspeaker connect-
ing leads when mounting the housing upper part, please see
Abb.: 5 - 10. The leads must point upwards.
5.10 Checks after Repair
1. Check the device to ensure safe functionality of the unit (see
„Device Check“ ➨ S. 2 - 4).
2. Depending on the work carried out the specific steps of the
TSC must be performed (see „Technical Safety Check (TSC)“ ➨
S. 7 - 1).
3. The activities carried out must be recorded in the following
check list.
Abb.: 5 - 10
Legende zu Abb. 5 - 10:
ItemDesignation
1 Loudspeaker connecting leads
1
