SpaceStation, 2.0 gb 5- 1
5
5-Disassembly / Assembly SpaceCover
SpaceCover
5.1 General
Remarks on Disassembly / Assembly
Before disassembling the unit, the system must be checked (see
„Device Check“ ➨ S. 2 - 4) to isolate the part to be exchanged.
All necessary steps to disassemble or dismount the complete unit
with all its subsystems and spare parts of the SpaceCover stand-
ard and the SpaceCover comfort are detailed in the following de-
scription. Steps that are not necessary can be skipped.
Note
All figures in this chapter depict the SpaceCover comfort. In gen-
eral, these figures also apply to the SpaceCover standard.
Note
Special screws for plastic housings are used in this unit. Pay at-
tention to the corresponding notes when you fit the screws.
Service Parts and Screw Kit
All small parts, such as cover caps, are contained in a SpaceSta-
tion service part kit.
Designation Ord. No.
Service part kit SpaceStation . . . . . . . . . . . . . . . . . . . . 3477 4335
with:
Release button
Release seal
Seal M-2K
Cover cap for housing
Cover cap for handle
Housing foot SPS
Mains seal F1A
Pole clamp lever
Pole clamp spring
O-ring 6.07 x 1.78
O-ring 12.0 x 2.0
2.0
