SpaceStation, 2.0 gb 3- 1
3
3-Disassembly / Assembly SpaceStation
SpaceStation, SpaceCover
3.1 General on the SpaceStation without Space-
Com
Remarks on Disassembly / Assembly of the SpaceStation with-
out SpaceCom
WARNING
DURING DISASSEMBLY AND ASSEMBLY THE OPERATOR/SERVICE
TECHNICIAN MUST WORK WITH VOLTAGES UP TO 115 / 230 V AC.
THESE VOLTAGES MAY CAUSE INJURIES WHICH ARE DANGEROUS
TO LIFE AND LIMB. THE NATIONAL AND INTERNATIONAL SAFETY
REGULATIONS ARE TO BE ADHERED TO. THE MAINS CABLE IS TO
BE REMOVED.
Before disassembling the unit, the system must be checked (see
„Device Check“ ➨ S. 2 - 4) to isolate the part to be exchanged.
All necessary steps to disassemble or dismount the complete unit
with all its subsystems and spare parts are detailed in the follow-
ing description. Steps that are not necessary can be skipped.
Note
Special screws for plastic housings are used in this unit. Pay at-
tention to the corresponding notes when you fit the screws.
2.0
