Disassembly / Assembly SpaceStation
3
3- 2 SpaceStation, 2.0 gb
Service Parts and Screw Kit
All small parts, such as cover caps, are contained in a SpaceSta-
tion service part kit.
Designation Ord. No.
Service part kit SpaceStation . . . . . . . . . . . . . . . . . . . . 3477 4335
with:
Release button
Release seal
Seal M-2K
Cover cap for housing
Cover cap for handle
Housing foot SPS
Seal, mains F1A
Pole clamp lever
Pole clamp spring
O-ring 6.07 x 1.78
O-ring 12.0 x 2.0
All screws used in the device are included in a SpaceStation screw
kit.
Designation Ord. No.
Screw kit SpaceStation . . . . . . . . . . . . . . . . . . . . . . . . . 3477 4343
Screw EJOT 30x9 WN 5452 TORX 10IP A2
Screw EJOT 30x12 WN 5452 TORX 10IP A2
Screw EJOT 30x16 WN 5451 TORX 10IP A2
Screw M5x45 A2 DIN912 TORX 25
Countersunk screw M5x12 TORX 25
Fillister-head screw M5x12 EN-ISO14583 A2
Nut M4
Insulating washer M3
Washer M4
Washer M5
Serrated lock washer M4
Serrated lock washer M5
SpaceStation without SpaceCom
