Unit Diagnosis / Calibration
2
2- 4 SpaceStation, 2.0 gb
The Most Important Error Modes
The following list specifies the most important error modes and
their clearance.
Note
The error list is in preparation.
Device Check
8 The first LED in the top charge condition
display of the operator and status display
field of the SpaceCover comfort lights up
red
Battery module of the SpaceCover com-
fort defective or too old
Replace battery module
9 The first LED in the bottom charge condi-
tion display of the operator and status
display field of the SpaceCover comfort
lights up red
Battery module of the SpaceCom defec-
tive or too old
Replace battery module
Alarm Possible Cause Fault Clearance
Table 2 - 2 Alarms of the SpaceCover comfort (Part 2 of 2)
UTS Activity Function If yes If no
1 Detach or loosen all connections and devices from
the SpaceStation
UTS 2
2 Connect the SpaceStation via the mains cable to
the mains
UTS 3
3 Insert one pump after the other in each slot The pump is locked UTS 4 TS 1
4 The pump can be released at any slot UTS 5 TS 1
5 Plug service connector SP on connector “F3” UTS 6
6 Insert the pump in the topmost slot and trigger a
staff call
The red LED of the service connector SP lights up UTS 7 TS 4
7 Remove the pump while it is switched on The red LED of the service connector SP goes out UTS 8 TS 4
8 Insert the switched-on pump in each other slot The red LED of the service connector SP lights up
when the lock engages
UTS 9 TS 4
9 A SpaceCover comfort with SpaceStation is in-
stalled
UTS 10 UTS 20
10 Mount and lock the SpaceCover comfort on the
SpaceStation
All luminous fields of the status and alarm display
line light up briefly during the self-test
UTS 11 TS 5
11 A short audible alarm sounds UTS 12 TS 7
Table 2 - 3 Device check (Part 1 of 2)
2.0
