Disassembly / Assembly SpaceStation
3
SpaceStation, 1.0 gb 3- 11
1.0
3.7 Release Button
Designation Ord. No.
Release button and release seal
(see „Service Parts and Screw Kit“ ➨ S. 3 - 2)
Disassembly
1. Press four release buttons (Abb.: 3 - 11 / Item 1) carefully
from the inside from the locking shaft using a screwdriver
and pull the buttons out of the housing.
Note
Check the release buttons for damage, especially within the notch
area, before fitting the buttons.
Abb.: 3 - 11
Legende zu Abb. 3 - 11:
ItemDesignation
1 Release button
3
