Disassembly / Assembly SpaceStation
3
3- 10 SpaceStation, 1.0 gb
1.0
Disassembly
1. Loosen three screws (Abb.: 3 - 10 / Item 3) and remove
screws together with the mains connector holder (Abb.: 3 -
10 / Item 1) and the mains seal F1A (Abb.: 3 - 10 / Item 2)
from the power supply.
Abb.: 3 - 10
Legende zu Abb. 3 - 10:
ItemDesignation
1 Mains connector holder
2 Mains seal F1A
3 Screw EJOT 30x9 WN 5452 TORX 10IP A2
1
2
3
