Procedural Instructions on the TSC
8
8- 4 SpaceStation, 2.0 gb
2.0
Functional Inspection
Mechanical
1. Check proper functioning of the lock of all pump slots with
one pump.
2. Check the battery compartment cover lock of the SpaceSta-
tion with SpaceCom for proper operation.
3. Check proper functioning of the lock to another SpaceStation
or a SpaceCover.
4. Check the battery compartment cover lock of the SpaceCover
comfort for proper operation.
Functional Check
1. Connect the SpaceStation to the mains.
2. In case of a SpaceStation with SpaceCom the following func-
tions are to be checked:
a) Fan in the housing back panel starts running for appr. 1
sec.
b) Status indicator (green) on the SpaceCom lights up
c) Alarm indicator (red) on the SpaceCom lights up for ap-
prox. 1 minute
3. Trigger an alarm with a pump at each slot. The red LED on the
service connector SP must light up.
When a SpaceCover comfort is fitted the alarm must also be
displayed in the status- and alarm display line of the Space-
Cover comfort; an audible alarm must sound.
4. Carry out a self-test of the SpaceCover comfort (actuate the
On- / Off button on theSpaceCover comfort), please see in-
structions for use.
Battery Check of the SpaceCover comfort
1. Insert a battery module in the SpaceCover comfort. After
start-up the battery charge condition is displayed in the top
charge condition display of the operator and status display
field of the SpaceCover comfort.
2. Disconnect the SpaceStation from the mains. An audible
alarm sounds and the status display colour on the operator
and status display field of the SpaceCover comfort changes
from green to yellow.
3. Possible displays are shown on the SpaceCover comfort.
4. Switch the SpaceStation or the SpaceStation column on and
then off via the SpaceCover comfort. A self-test is carried out.
