Braun SpaceStation User Manual

Unit Diagnosis / Calibration
2
SpaceStation, 2.0 gb 2- 7
2.0
5 Exchange processor PCB SPCC All luminous fields of the status and alarm display
line light up briefly during the self-test
All LEDs of the operator and status display field light
up briefly
The green LED on the operator and status display
field lights up
UTS 10 TS 6
6 Replace interface board in the SpaceStation UTS 10
7 Replace loudspeaker A short audible alarm sounds UTS 14 TS 8
8 Exchange processor PCB SPCC UTS 14
9 Replace interface board in the SpaceStation The charge state of the battery module is displayed
on the operator and status display field
UTS 15 TS 10
10 Exchange the housing upper part SPCC UTS 15
11 Exchange the housing upper part SPCC The loudness changes UTS 16 TS 12
12 Exchange processor PCB SPCC UTS 16
13 Exchange processor PCB SPCC The infusion is displayed green in the status and
alarm display line
UTS 18 TS 14
14 Replace interface board in the SpaceStation UTS 18
15 Exchange processor PCB SPCC The alarm is displayed red in the status and alarm
display line
UTS 20 TS 16
16 Replace interface board in the SpaceStation UTS 20
17 Pull off the fan connecting cable on the SPCO
board and trigger the fan with 12 V DC. Connect
the (+) pole to the connector pole with red wires
and the (-) pole to the connector pole with black
wires
The fan is running TS 19 TS 18
18 Exchange fan UTS-COM 5
19 The status indicator (green) of the SpaceCom lights
up
TS 20 TS 21
20 Replace the SPCO board UTS-COM 5
21 Replace interface board in the SpaceStation UTS-COM 5
22 Replace battery module of the SpaceStation The charge condition of the battery module is dis-
played in the bottom charge condition display of
the operator and status display field of the Space-
Cover comfort
UTS-COM 8 TS 23
23 Replace the SPCO board The charge condition of the battery module is dis-
played in the bottom charge condition display of
the operator and status display field of the Space-
Cover comfort
UTS-COM 8 TS 24
24 Replace interface board in the SpaceStation UTS-COM 8
TS Activity Function If yes If no
Table 2 - 5 Trouble shooting (Part 2 of 2)
