Disassembly / Assembly SpaceCover
5
SpaceStation, 1.0 gb 5- 7
1.0
3. Pull the connector lock (Abb.: 5 - 6 / Item 1) on the processor
PCB SCc upward.
4. Remove the rubber cable to the operator panel.
5. Remove two seals (Abb.: 5 - 5 / Item 2) in the housing bottom
part.
Abb.: 5 - 6
Legende zu Abb. 5 - 6:
ItemDesignation
1 Connector lock
1
