X7-8-Install-IG100 Installation Guide
Brocade
®
X7-8 Director Hardware Installation Guide
SKU Part Number Short Description Introduced (OS) Currently Supported
FC32-64 Blade
XBR-X6-0164
Port blade with 16 QSFP+ Flexports
that
can be configured for FC or FCoE
operation. Each port can operate at
speeds up to 4x32Gb/s port for a total
of 64 32Gb/s ports per blade with FC
transceivers installed. Optionally, you can
install Ethernet transceivers and configure
for FCoE operation. Various GbE speeds
are supported.
Fabric OS 9.0.0 Yes
FC64-48 Blade
XBR-X764-0148
Port blade with 48 front-end 64Gb/s
FC SFP+ ports with the edge switch
interconnect to the core blades. All FC
blade features are supported. Supported
SFPs include 10Gb/s, 32Gb/s, and 64Gb/
s FC.
Fabric OS 9.0.0
Yes
FC32-X7-48 Blade
XBR-X732-0148
Port blade with 48 front-end 32Gb/s FC
SFP+ ports with edge switch interconnect
to the core blades. All FC blade features
are supported. Supported SFPs include
32Gb/s, 16Gb/s, and 10Gb/s FC.
Fabric OS 9.0.0
Yes
CPX7 Blade
XBR-CPX7-0103 Control processor (CP) blade Fabric OS 9.0.0 Yes
CR64-8 Blade
XBR-X78-0106 Core routing blade provides 384 backend
FC links to the port blades in the
X7-8 Director. Each CR64-8 blade
provides 16 QSFP connections supporting
64 Gen 7 ICL ports.
Fabric OS 9.0.0
Yes
SX6 Blade
XBR-SX6-0000 Extension blade with 16 32Gb/s Fibre
Channel SFP+ ports, 16 10GbE SFP+
ports, and 2 40GbE QSFP+ ports
Fabric OS 8.0.1 Yes
WWN Card
XBR-X7-0124 World Wide Name card Fabric OS 9.0.0 Yes
Blade Sot Filler
Panel
XBR-X7-0128 Required to cover empty slot to maintain
airflow in chassis.
Fabric OS 9.0.0 Yes
Power Supply
Assembly Slot
Filler Panel
XBR-X6-0130 Required to cover empty slot to maintain
airflow in chassis.
Fabric OS 8.0.1 Yes
The following blades require optics that are labeled with an SEC designation:
Brocade FC64-48 Port Blade
Brocade FC32-X7-48 Port Blade
The following image provides an example of an optic label with SEC in the description (32G LW-SEC 10km).
X7-8-Install-IG100
10
Broadcom
