X7-8 Director Hardware Installation Guide
•
XBR–DCX-0120 Contains shelf brackets that telescope from 68.58 cm (27 in.) to 78.74 cm (31 in.) to fit the majority of
racks.
•
XBR–DCX-0152 - Contains 55.88 cm (22 in.) fixed shelf brackets that adjust to 68.58 cm (27 in.).
Observe the following cautions when mounting this device:
•
Use Electronic Industries Association (EIA) standard racks. Ensure that the space in the 48.3 cm (19-in.) EIA rack is
14U high.
•
Verify that the additional weight of the chassis does not exceed the weight limits of the rack.
•
Hardware devices illustrated in these procedures are only for reference and may not depict the device you are
installing into the rack.
Time and Items Required
Allow approximately one hour to unpack and install a device in a rack.
The following tools are required when installing the 14U Rack Mount Kit for Four-Post Rack:
•
Torque screwdriver with No. 2 Phillips screwdriver tip
•
Slotted (flat blade) screwdriver
•
Hydraulic or assisted lift with a minimum raise of 140 cm (55 in.) and a minimum capacity of 113 kg (250 lb)
Parts List
The following table lists 14U Rack Mount Kit parts and quantities for different installations. See the figure following the
table to identify these parts.
Table 7: 14U Rack Mount Kit Parts and Quantities
Description Installation Quantity
Left rack mount shelf bracket (rail brackets may differ from ones shown in figure) All 1
Right rack mount shelf bracket (rail brackets may differ from ones shown in figure) All 1
10-32 x 5/8 in. (1.58 cm) panhead Phillips screw and washer (torque to 37 cm-kg
[32 in.-lb])
All 6
10-32 clip nut For rack rails with round holes 6
1/4-20 x 1/2 in. (1.27 cm) panhead Phillips screw with lock washer (torque must be
set to 92 cm-kg [80 in.-lb])
For rack rails with round holes 16
10-32 retainer nut For rack rails with square holes 6
1/4-20 x 1/2 in. (1.27 cm) panhead Phillips screw with thread locker (torque must
be set to 92 cm-kg [80 in.-lb])
For rack rails with square holes 16
3/8 in. (0.953 cm) alignment washer For rack rails with square holes 16
NOTE
Depending on the device and installation, not all the parts may be used on the device type.
