X7-8-Install-IG100 Installation Guide
Brocade
®
X7-8 Director Hardware Installation Guide
DANGER
Make sure that the power source circuits are properly grounded, and then use the power cord supplied with the
device to connect it to the power source.
CAUTION
Use a separate branch circuit for each power cord, which provides redundancy in case one of the circuits fails.
DANGER
High Touch Current. Earth connection essential before connecting supply.
CAUTION
All devices with AC power sources are intended for installation in restricted access areas only. A restricted
access area is a location where access can be gained only by trained service personnel through the use of a
special tool, lock and key, or other means of security.
CAUTION
The maximum input voltage for connection to the HVAC/HVDC power supply should not exceed 305 VAC and
400 VDC.
CAUTION
The maximum input voltage for connection to the HVAC/HVDC power supply should not exceed 305 VAC and
400 VDC .
CAUTION
For removal of the metal cable restraint cover under the high voltage power supply inlet, remove the 2 Torx
screws.
Lifting Precautions
DANGER
Use safe lifting practices when moving the product.
CAUTION
Do not attempt to lift or support the chassis by the logo bezel attached over the port-side air vents.
Laser Precautions
DANGER
Use only optical transceivers that are qualified by Broadcom and comply with the FDA Class 1 radiation
performance requirements defined in 21 CFR Subchapter I, and with IEC 60825 and EN60825. Optical products
that do not comply with these standards might emit light that is hazardous to the eyes.
X7-8-Install-IG100
