Broadcom Brocade X7-8 User Manual

X7-8-Install-IG100 Installation Guide Brocade
®
X7-8 Director Hardware Installation Guide
4. Status LED for Left FC Port
The following table describes the port blade LED patterns and the recommended actions for those patterns.
Table 13: Port Blade LED Descriptions
LED Purpose Color Status Recommended Action
Steady green The blade is operational. No action is required. Power
No light (LED is off) The blade is not powered on. Ensure that the blade is firmly
seated, with ejectors pushed in
fully to the center of blade and
ensure that the captive screw for
each ejector is fully tightened.
No light (LED is off) The blade is either healthy or
does not have power.
Verify that the power LED is on.
Steady amber The blade is faulty. Ensure that the blade is firmly
seated and check the status
by entering the slotShow
command. If the LED remains
amber, consult the device
supplier.
Slow-flashing amber (on 2
seconds, then off 2 seconds)
The blade is not seated correctly
or is faulty.
Pull the blade out and reseat
it. If LED continues to flash,
replace the blade.
Status
Fast-flashing amber (on 1/2
second, then off 1/2 second)
Environmental range has been
exceeded.
Check for out-of-bounds
environmental condition and
correct it.
The port has no incoming
power, or there is no light or
signal carrier detected.
Verify that the power LED is on,
check the transceiver and cable.
Polling is in progress. Allow 60 seconds for polling to
complete.
No light (LED is off)
The connected device is
configured in an offline state.
Verify the status of the
connected device.
Steady green Port is online (connected to
an external device) but has no
traffic.
No action is required.
Slow-flashing green (on 1
second, then off 1 second)
Port is online but segmented,
indicating a loopback plug or
cable or an incompatible switch.
Verify that the correct device is
attached to the chassis.
Fast-flashing green (on 1/4
second, then off 1/4 second)
Port is in internal loopback
(diagnostic).
No action is required.
Flickering green The port is online, with traffic
flowing through the port.
No action is required.
FC port Status
Steady amber The port is receiving light or
signal carrier, but it is not online
yet.
Reset the port from
the workstation using
the portEnable or
portCfgPersistentEnable
command.
X7-8-Install-IG100
75
Broadcom
