Brother BAS-761 - Programming Example; Programming for each Stitch

Programmer
22
Chapter 2 Programming with Help Function
Programming example
Frequently used programming method is explained here. Refer to "Programming" (page 58) for function
and operation of each icon.
Programming for each stitch
Program each stitch according to the pattern. The
example in the left is used for explanation.
1
Programming
1. Press
P
.
The work clamp comes down and the programmer screen is
displayed.
2. Select with , then press .
3. Move the needle with
. Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
4. Select with , then press .
5. Move the needle with
. Press
when the needle point is at point B of the
pattern.
6. Repeat step 5 and create the program to
point C.
