Programmer
72
Chapte 2 Programming with Help Function
Editing program
Edit the retrieved or created data.
The following options are available as editing functions.
Moving a pattern in parallel. (Changes the sewing start position.)
Changing the pitch of the program. The pitch of the needle tacking data is not
changed. The following settings of attributes become invalid when changing the
pitch. Set them again after changing the pitch.
* Two step tension setting
* Two row switch
* Option output
* Slow conversion
Resizing the program in the scale between 90 to 110 %.
All the settings of attributes become invalid if the pattern is resized without changing
the stitch length. Set the attributes after resizing the pattern.
Rotating a pattern clockwise in range of 1 to 359 degrees. The reference point of
rotation is the center of the external shape of the data.
Rotating a pattern counterclockwise in the range of 1 to 359 degrees. The reference
point of rotation is the center of the external shape of the data.
Modifying the X origin (the position where the working clamp holds the pocket on
the folding machine side).
It is available only in the help mode.
The position of the working clamp can be adjusted horizontally with the position
detected by the X origin sensor as 0. Values -2.0 to 5.0 mm are available for the
position. The values indicated in the right side of the working clamp are positive and
those indicated in the left side are negative.
1. Select , then press .
2. Select an editing function, then press .
