Chaprter 3 Programming with Command Function
Programmer
99
Adding shunting point before the first stitch
An shunting point is added before the sewing start
position. The example in the left is used for explanation
of setting shunting point A.
The shunting point is a provisional point provided for prevention of the work clamp interference with impediments
on it when it moves directly from the standby position to the sewing start position.
1
Calling data
1. Specify the program number on the operation
panel, then press
switch to read the data.
Refer to "Using the operation panel of the main body"(page 128)
for detailed operation.
2
Moving to position 1
1. Press
1
, then press .
The needle moves to the sewing start position.
3
Programming a new point
1. Press
F
.
2. Move the needle with
so that the
needle point is at A of the pattern.
Record the coordinates (values of and ).
3. Press
L
.
A is programmed.
4. Press
F
.
5. Move the needle with
to the opposite
position of coordinates recorded in step 2, then
press
L
.
