Brother BAS-761 - Editing the current data

Programmer
62
Chapter 2 Programming with Help Function
Creating needle drop data
Create needle drop data for the current needle position.
1. Select
, then press .
2. Move the needle with , then press .
Creating feed data
Create (feed) data of the needle to move the needle from the current position to the next
without dropping it.
1. Select , then press .
2. Move the needle with , then press .
Remaining plot count
Distance from the previous point in the
direction of X or Y axis
Remaining plot count
Distance from the previous point in the
direction of X or Y axis
