Brother BAS-761 - Adding Shunting Point before the First Stitch

Programmer
48
Chapter 2 Programming with Help Function
Adding shunting point before the first stitch
An shunting point is added before the sewing start
position. The example in the left is used for
explanation of setting shunting point A.
The shunting point is a provisional point provided for prevention of the work clamp interference with impediments
on it when it moves directly from the standby position to the sewing start position.
1
Calling data
1. Press
P
.
The work clamp comes down and the programmer screen is
displayed.
2. Select with , then press .
3. Select
with , then press .
4. Input the program number, then press
.
5. Press
ESCESC
.
2
Moving to position 1
1. Select with , then press .
2. Press
1
, then press .
The needle moves to the sewing start position.
3. Press
ESCESC
.
