Brother BAS-761 - Creating a Curve

Programmer
59
Chapter 2 Programming with Help Function
2. Input the stitch length, then press .
3. Move the neelde with , then press .
Creating a curve
Increase the number of plotting points to create a smoother curve.
One to 99 points are available for plotting.
1. Select
, then press .
2. Input the stitch length, then press .
3. Move the needle with , then press .
4. Press twice at the sewing end position.
Check that both values are
0.00 mm.
Stitch length
Distance from the previous point in the
direction of X or Y axis
Remaining plot count
Remaining plot count
Distance from the previous point in the
direction of X or Y axis
Tacking pitch
