Ending program
1. Press
P
.
Double stitch
A double stitch is programmed to make two lines
with a constant width.
The example in the left is used for explanation of a
double stitch to the right of sewing direction.
When the line changes from straight to curve or curve to straight as in points B or E, be sure to press
L
7
8 9
to make a split.
More intermediate points such as points C or D will create smooth curves.
Programming
1. Press
P
.
The work clamp comes down and the programmer screen is
displayed.
2. Move the needle with . Press
L
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
3. Press
2
3 0
, then press
M
.
2
is the command for the double stitch. Input the
width of the double stitch in
. 3.0 mm is input in the
example.
4. Input the stitch length, then press
M
.
3.0 mm is input in the example.
Input 030 to make the stitch length to 3.0 mm.
5. Create the program to point F in the similar
manner of curve program.
If a straight line is present as in the example, press
L
7
8 9
in the position where the curve is changed to
the straight, and vice versa.
L
Sewing
width
