Programmer
89
Chaprter 3 Programming with Command Function
Inputting the end code
1. Press
E
1
1 1
.
The needle goes back to the sewing start position after moving
to points G and H.
To stitch between point H and point A, press
9 9 9
to put the needle position on point H and stitch a straight line to
point A, then press
E
1
1 1
.
Saving
1. Specify the program number on the
operation panel, then press
switch for
writing into the floppy disk.
Refer to "Using the operation panel of the main body"(page 131)
for detailed operation.
Ending program
1. Press
P
.
Feed
After breaking thread halfway through sewing, a feed
is set to start sewing again from a different position.
The example in the left is used for explanation of
programming an inner pattern with a feed after an
outer pattern.
Programming
1. Press
P
.
The work clamp comes down and the programmer screen is
displayed.
2. Move the needle with . Press
when the needle point is at point A of the
pattern.
The first stitch (point A) is programmed.
To Next Page
