Brother BAS-761 - Moving the Shunting Point

Programmer
51
Chapter 2 Programming with Help Function
Moving the shunting point
The position of the shunting point is moved. The
example in the left is used for explanation of moving
the shunting point from A to B.
1
Calling data
1. Press
P
.
The work clamp comes down and the programmer screen is
displayed.
2. Select with , then press .
3. Select
with , then press .
4. Input the program number, then press
.
5. Press
ESCESC
.
2
Moving to position A
1. Select with , then press .
2. Press
1
and press .
The needle moves to the start position.
3. Press
ESCESC
.
