Programmer
63
Chapter 2 Programming with Help Function
Editing the current data
Data of the needle position after a certain position can be moved.
The following options are available as editing functions.
Moving data of the needle position after the current position in parallel by feeding
By feeding
Moving data of the needle position after the current position in parallel by stitching
with the specified stitch length.
By stitching with the
specified stitch length
Moving data of the needle position after the current position in parallel by stitching
when the moving distance is 6.0 mm or less and by feeding if it is more than 6.0 mm.
All the stitches after A
are moved in parallel.
Offsetting double stitch data to the left side of the sewing path
Offsetting double stitch data to the right side of the sewing path
Adjust the needle position before editing.
Refer to "Checking the program setting and setting attribute" (page 69) for adjustment.
1. Select
, then press .
To Next Page
