Brother BAS-761 - Page 65

Programmer
64
Chpater 2 Programming with Help Function
If is selected
1. Adjust the destination with , then press .
If is selected
1. Input the stitch length, then press .
2. Adjust the destination with , then press .
If is selected
1. Adjust the destination with , then press .
Distance from the previous point in the
direction of X or Y axis
Stitch length
Distance from the previous point in the
direction of X or Y axis
