Programmer
27
Chapter 2 Programming with Help Function
5. Input the stitch length, then press .
3.0 mm is input in the example.
Input 030 to make the stitch length to 3.0 mm.
6. Move the needle with . Press
when the needle point is at point B of the
pattern.
7. Repeat step 6 and create the program to
point E.
8. When point E is programmed, press
again.
Point E becomes a corner and is programmed. To change the
stitch length, press
ESCESC
for resetting.
9. Create the program to point I.
10. When point I is programmed, press
again.
11. Press
ESCESC
twice.
2
Inputting the end code
1. Select with , then press .
2. Press
.
Press and the needle returns to the first stitch(point A).
3. Press
ESCESC
.
The needle returns to the standby position.
