Brother DCP-L5652DN Service Manual

2-72
Confidential
 Error code 9701
A tray set to duplex printing-incompatible size was specified in duplex printing.
Error code 9702
When printing from paper tray 1, a paper size not supported for paper tray 1 was specified
from the driver.
Error code 9703
When printing from paper tray 2, a paper size not supported for paper tray 2 was specified
from the driver.
Error code 9704
When printing from paper tray 3, a paper size not supported for paper tray 3 was specified
from the driver.
Error code 9705
When printing from paper tray 4, a paper size not supported for paper tray 4 was specified
from the driver.
Error code 9706
When printing from paper tray 5, a paper size not supported for paper tray 5 was specified
from the driver.
 Error code 9B03
Only T2 tray is set for A4 / Letter / Legal / Folio but T2 is set as "Skip Tray".
Error code 9B04
Only T3 tray is set for A4 / Letter / Legal / Folio but T3 is set as "Skip Tray".
Error code 9B05
Only T4 tray is set for A4 / Letter / Legal / Folio but T4 is set as "Skip Tray".
Error code 9B06
Only T5 tray is set for A4 / Letter / Legal / Folio but T5 is set as "Skip Tray".
<User Check>
• Select the specified paper size in the driver and set paper with the same size to the
specified paper tray.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Check the paper or Skip Tray setting.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
