Brother DCP-L5652DN Service Manual

2-125
Confidential
4.14.4"Paper Low" message does not disappear
<User Check>
• Refill the paper in the appropriate paper tray.
• Turn the power switch OFF and then ON again.
Step Cause Remedy
1
Damaged plate-up plate in the
paper tray
Replace the paper tray.
2 Paper feed motor failure Replace the paper feed motor.
3
Damaged plate push-up
mechanism in the machine
Replace the main frame L ASSY.
4 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
