Brother DCP-L5652DN Service Manual

3-3
Confidential
3. SCREW CATALOGUE
Fig. 3-2
Screw pan (S/P washer)
M3.5x6
Taptite cup S
M3x6 SR
Taptite cup S
Taptite bind B
Taptite bind B
M4x30
Taptite bind B
M3x10
Taptite bind B
M4x12
Taptite cup B
Taptite cup B
M3x10
Taptite pan B
Screw pan (S/P washer)
Taptite pan B
M3x8
Taptite pan B
M4x14
Screw pan (S/P washer)
M3x12DB
Taptite cup S
M3x8 SR
Screw cup
Screw cup
M3x8
Screw pan
Screw pan
M4x8
Taptite flat B
Taptite flat B
M3x10

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
