Brother DCP-L5652DN Service Manual

5-3
Confidential
1.2 List of Maintenance Mode Functions
Function
code
Function Refer to:
01 Initialize EEPROM parameters 1.3.1
08 ADF performance test 1.3.2
09 Print quality test pattern 1.3.3
10 Set worker switches (WSW) 1.3.4
11 Print worker switch (WSW) setting data 1.3.4
12 Check LCD operation 1.3.5
13 Check control panel key operation 1.3.6
18 Save NetConfig data 1.3.7
25 Display software version 1.3.8
28 Change setting for OnePushDemo function 1.3.9
32 Check sensor operation 1.3.10
33 Display LAN connection status 1.3.11
43 Set PC print functions 1.3.12
45
Change USB No. return value / Adjust left-end print
position / Adjust upper-end print position / Set HEXDUMP
Mode
1.3.13
46
Adjust printable range for each speed level
(Full speed / Half speed for thick paper / Quiet Mode)
1.3.14
52 Set country / language 1.3.15
53
Transfer received fax data / log information
(fax models only)
1.3.16
54 Fine-tune scanning position 1.3.17
55 Acquire white level data and set CIS scan area 1.3.18
61 Adjust touch panel 1.3.19
67 Continuous print test 1.3.20
69 Print frame pattern (single-side printing) 1.3.21
70 Print frame pattern (duplex printing) 1.3.22
71 Print test pattern 1.3.23
74 Configure for country/region and model 1.3.24
77 Print maintenance information 1.3.25
78 Check main fan operation 1.3.26
79 Delete fax data 1.3.27
80 Display machine log information 1.3.28

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
