1.3.17 Fine-tune scanning position (function code: 54)
<Function>
This function is used to adjust the scanning start/end positions.
<Operating Procedure>
(1) Press the [5], and then the [4] key in the initial state of maintenance mode.
"▲: MAIN ▼: SUB" is displayed on the LCD.
(2) Press the [▲] key to adjust the main scanning. Press the [▼] key to adjust the vertical
scanning.
• For Duplex scanning models
"▲: ADF ▼: FB" is displayed on the LCD. To adjust the ADF scanning position, press
the [▲] key and proceed to the procedure (3). To adjust the FB scanning position,
press the [▼] key and proceed to the procedure (4).
• For single-side scanning models
Proceed to the procedure (4).
(3) "▲: FRONT ▼: BACK" is displayed on the LCD.
Press the [▲] key to adjust the first side. Press the [▼] key to adjust the second side.
The currently set value is displayed on the LCD.
(4) To increase the adjustment value, press the [▲] key. To decrease the adjustment value,
press the [▼] key. (refer to the figure below)
(5) Press the [SET] key after adjusting the value. "ACCEPTED" is displayed on the LCD,
and the machine returns to the initial state of maintenance mode.
Fig. 5-9
Note:
• When the [X] key is pressed, the machine stops correcting the adjusting value and
returns to the initial state of maintenance mode.
723VLGH
/HIWVLGH
5LJKWVLGH
%RWWRPVLGH
To Next Page
