Brother DCP-L5652DN Service Manual

3-4
Confidential
4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
Fuser unit line cover R Taptite bind B M4x12 1 0.80.1 (81)
Fuser unit line cover L Taptite pan B M4x14 1 0.80.1 (81)
Fuser unit Taptite pan B M4x14 1 0.80.1 (81)
Side cover L Taptite bind B M4x12 2 0.80.1 (81)
Side cover R Taptite bind B M4x12 2 0.80.1 (81)
Main shield plate Screw cup M3x8 (Black) 3 0.450.05 (4.50.5)
ADF FG harness
Modem FG harness L
FB FG harness
Panel FG harness Taptite cup S M3x8 SR 1 0.60.1 (61)
ADF/document scanner unit Taptite bind B M4x12 6 0.80.1 (81)
ADF unit (Hinge L ASSY) Taptite bind B M4x12
(Black)
10.80.1 (81)
Hinge L ASSY Taptite bind B M4x12 3 0.80.1 (81)
Hinge R support Taptite cup B M3x10 1 0.50.1 (51)
Hinge arm R Taptite cup B M3x10 3 0.50.1 (51)
ADF front cover Taptite cup B M3x10 2 0.50.1 (51)
ADF separation holder ASSY Taptite cup B M3x10 1 0.50.1 (51)
Upper document chute Taptite cup B M3x10 6 0.50.1 (51)
Panel unit Taptite cup B M3x10 4 0.50.1 (51)
LCD presser Taptite cup B M3x10 3 0.50.1 (51)
Shield plate cover Taptite cup B M3x10 4 0.50.1 (51)
USB host P
CB ASSY Taptite bind B M4x12 2 0.80.1 (81)
Scanner top cover Taptite bind B M4x12 8 0.80.1 (81)
Modem FG harness R
(Frame R side)
Taptite cup S M3x6 SR 1 0.60.1 (61)
Joint cover ASSY Taptite bind B M4x12 6 0.80.1 (81)
Modem FG harness L
(Modem side)
Screw pan (S/P washer)
M3.5x6
10.60.1 (61)
Modem FG harness R
(Modem side)
Screw pan (S/P washer)
M3.5x6
10.60.1 (61)
Modem shield plate Taptite bind B M4x12 2 0.80.1 (81)
Modem shield cover Screw pan (S/P washer)
M3.5x6
10.60.1 (61)
Modem PCB ASSY Taptite cup S M3x6 SR 2 0.50.1 (51)
Veil cover lower Screw cup M3x8 (Black) 1 0.450.05 (4.50.5)
Main PCB ASSY Screw cup M3x8 (Black) 4 0.450.05 (4.50.5)
Top bar
(T1: Models with 520-sheet)
Taptite bind B M4x12
2
0.80.1 (81)
Laser unit Taptite cup S M3x8 SR 4 0.80.05 (80.5)

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
