Brother DCP-L5652DN Service Manual

2-38
Confidential
4. TROUBLESHOOTING
4.1 Error Cause and Remedy
 Error code 0102
Communication error between the engine ASIC and motor driver or faulty motor driver.
 Error code 0201
Cannot detect the synchronized signal of the paper feed motor. The speed of the paper feed
motor does not stabilize within the specified time.
 Error code 0203
Eject motor failure was detected.
Step Cause Remedy
1
Connection failure of the paper
feed motor harness
Reconnect the paper feed motor harness.
2 Paper feed motor failure Replace the paper feed motor.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the paper
feed motor harness
Reconnect the paper feed motor harness.
2 Damaged fuser gear Replace the fuser gear.
3 Paper feed motor failure Replace the paper feed motor.
4 Damaged fuser unit Replace the fuser unit.
5
Low-voltage power supply PCB
failure
Replace the low-voltage power supply PCB
ASSY.
6
Damaged part in drive sub
ASSY
Replace the main frame L ASSY.
7 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the eject
motor harness
Reconnect the eject motor harness.
2 Eject motor failure Replace the eject motor.
3
Low-voltage power supply PCB
failure
Replace the low-voltage power supply PCB
ASSY.
4 Damaged part in eject gears Replace the main frame L ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5652DN Specifications

General

Printer Type	Laser
Functions	Print, Copy, Scan
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Memory	256 MB
Processor	800 MHz
Monthly Duty Cycle	Up to 50, 000 pages
Print Speed	42 ppm
Print Resolution	1200 x 1200 dpi
Paper Input Capacity	250 sheets
Scanner Resolution	Up to 1200 x 1200 dpi
Connectivity	USB, Ethernet
Mobile Printing	Brother iPrint&Scan, Google Cloud Print, AirPrint, Mopria
Toner Yield	Standard: 3, 000 pages, High Yield: 8, 000 pages
