1.3.12 Set PC print functions (function code: 43)
<Function>
This function is used to change the settings of the various print functions summarized in the
table below.
<Operating Procedure>
(1) Press the [4], and then the [3] key in the initial state of maintenance mode. "Manual
Feed" is displayed on the LCD.
(2) Press the [▲] or [▼] key to display the function you want to change the setting of, and
press the [SET] key.
(3) For fixed parameters (On/Off, etc.), press the [▲] or [▼] key to display the setting you
want to apply, and press the [SET] key. For parameters requiring numerical value entry,
use the keypad to enter a numerical value directly, and press the [SET] key.
(4) When the [X] key is pressed, the machine returns to the initial state of maintenance
mode.
 Setting functions
LCD Description Set value Default
Manual Feed Manual feed setting On/Off Off
Resolution Print resolution 300/600/1,200 dpi 600 dpi
Toner Save Toner save mode setting On/Off Off
Density Print density level -6 to 6 0
JB-Can Time Time until host timeout after a job
is canceled
0 to 225 seconds 10 seconds
Sleep Time Time until sleep mode is entered 0 to 99 minutes 1 minute
Page Protection Page memory setting Off/Letter/A4/Legal/Auto Auto
Emulation Emulation (print language)
setting
Auto/HP/PS Auto
Auto I/F Time Interface open time setting 1 to 99 seconds 5 seconds
Media Type Paper type setting Thin/Plain/Thick/
Thicker/Transparency/
Recycled/Bond/
Envelopes/EnvThin/
EnvThick
Plain or Thin
Paper Size Image development area setting Letter/Legal/A4/
Executive/ISOB5/JISB5/
A5/ISOB6/A6/Monarch/
C5/COM10/DL/DLL/
A4Long/Postcard/Folio
Letter or A4
Copies Number of copies 1 to 99 copies 1 copy
Orientation Print direction setting Portrait/Landscape Portrait
P-Pos X-Offset Print position offset in X
(landscape) direction
-500 to 500 (1/300 dpi) 0 (1/300 dpi)
P-Pos Y-Offset Print position offset in Y (portrait)
direction
-500 to 500 (1/300 dpi) 0 (1/300 dpi)
Auto FF Auto Form Feed setting On/Off Off
Auto FF Time Time until Auto Form Feed
timeout
1 to 99 seconds 5 seconds
FF Surpress Blank page skip setting On/Off Off
